General Purpose Industrial Oven Model GP450B

Standard Features

• 300°C maximum operating temperature
• Carbolite Gero 301 controller, with single ramp to set-point & process timer
• Powerful vertical (A) or horizontal (B) airflow for optimum uniformity
• Built to withstand the rigours of a production environment
• Long lasting, polished 430 grade ferritic stainless steel internal case
• Robust external construction from steel section & zinc coated mild steel panels
• Mineral insulated metal sheathed heating elements
• low thermal mass insulation for high energy efficiency
• Adjustable chamber ventilation

Options (specify these at time of order)

• Over-temperature protection (recommended to protect valuable contents & for unattended operation)
• A range of sophisticated digital controllers, multi-segment programmers and data loggers is available. These can be fitted with RS232, RS485 or Ethernet communications
• Access port for independent thermocouple
• Cable entry ports
• Bespoke specifications are available for AMS2750 (Nadcap) compliant applications
• Additional shelves
• Optional floor stand

GP450B

Max temp (°C)	300
Volume (litres)	450

Heat-up time (mins)	75
Recovery time (mins)	35
Temp stability (°C)	±0.5
Temp uniformity (°C)	±5.0
Dimensions: Internal H x W x D (mm)	610 x 1220 x 610
Dimensions: External H x W x D (mm)	910 x 1800 x 850
Shelves fitted / accepted	3 / 5
Shelf loading each / total (kg)	20 / 60
Doors	Double door
Configuration	Bench-top
Air changes / hr
